Series & Parallel Resonance (Detailed AKTU Notes)
Table of Contents
1. Introduction
2. What is Resonance
3. Series Resonance
4. Condition for Resonance
5. Resonant Frequency
6. Impedance at Resonance
7. Current Behaviour
8. Voltage Behaviour
9. Power Factor
10. Quality Factor
11. Bandwidth
12. Parallel Resonance
13. Series vs Parallel Resonance
14. Applications
15. Important Exam Points
16. Conclusion
Introduction
Resonance is one of the most important topics in electrical engineering, especially for AKTU first-year students studying basic electrical engineering. It plays a vital role in understanding the behavior of AC circuits containing resistors, inductors, and capacitors.
In many real-world electrical and electronic systems, resonance is used to select frequencies, improve efficiency, and control signal behavior. Understanding resonance will help students grasp advanced topics like filters, communication systems, and power electronics.
This article provides a detailed explanation of series and parallel resonance, including formulas, derivations, characteristics, and applications.
What is Resonance?
Resonance in an electrical circuit occurs when the inductive reactance (XL) becomes equal to the capacitive reactance (XC). At this condition, the reactive effects cancel each other.
XL = XC
Since inductors store energy in magnetic form and capacitors store energy in electric form, at resonance, energy continuously transfers between these two components.
This leads to special circuit behavior where impedance, current, or voltage reaches extreme values depending on circuit configuration.
Series Resonance
In a series RLC circuit, resistor (R), inductor (L), and capacitor (C) are connected in series. The same current flows through all components.
At resonance condition:
XL = XC
The inductive reactance cancels the capacitive reactance, making the circuit purely resistive.
This results in minimum impedance and maximum current flow in the circuit.
Series resonance is also called "Voltage Resonance" because large voltages can appear across the inductor and capacitor.
Condition for Resonance
The condition for resonance is:
XL = XC
Mathematically:
2πfL = 1 / (2πfC)
By solving this equation, we obtain the resonant frequency.
Resonant Frequency
The frequency at which resonance occurs is called the resonant frequency.
Formula:
f = 1 / (2π√LC)
This formula is applicable for both series and parallel resonance circuits.
At this frequency, the circuit exhibits special electrical properties such as unity power factor and maximum energy exchange.
Impedance at Resonance
In a series RLC circuit, impedance is given by:
Z = √(R² + (XL - XC)²)
At resonance:
XL = XC → Z = R
Thus, impedance becomes minimum and equal to resistance.
In parallel resonance, impedance becomes maximum.
Current Behaviour
In series resonance:
Current is maximum because impedance is minimum.
In parallel resonance:
Line current is minimum, but branch currents in L and C are high.
Voltage Behaviour
In a series resonant circuit, voltage across inductor and capacitor can be much higher than supply voltage due to energy exchange.
This phenomenon is known as voltage magnification.
Power Factor
At resonance, power factor becomes unity:
cosφ = 1
This means voltage and current are in phase, and maximum power is transferred.
Quality Factor (Q-Factor)
Quality factor measures the sharpness of resonance.
For series circuit:
Q = (1/R) √(L/C)
Higher Q indicates sharper resonance and better selectivity.
Bandwidth
Bandwidth is the range of frequencies over which the circuit operates effectively.
Bandwidth = f2 - f1
Also:
Bandwidth = f / Q
Narrow bandwidth means high selectivity.
Parallel Resonance
In a parallel RLC circuit, resistor, inductor, and capacitor are connected in parallel.
At resonance:
XL = XC
The circuit draws minimum current and impedance becomes maximum.
Parallel resonance is also known as "Current Resonance."
Although line current is small, circulating currents between L and C are large.
Series vs Parallel Resonance
Series Resonance:
- Impedance minimum
- Current maximum
- Voltage magnification
- Used in tuning circuits
Parallel Resonance:
- Impedance maximum
- Current minimum
- Current magnification
- Used in filters
Applications
Resonance is widely used in electrical and electronic systems:
- Radio and TV tuning circuits
- Band-pass and band-stop filters
- Oscillators
- Wireless communication systems
- Power system stability
Important Exam Points
Students should remember:
- Formula of resonant frequency
- Condition XL = XC
- Difference between series and parallel resonance
- Q-factor formula
- Bandwidth relation
Numerical problems are frequently asked in AKTU exams, so practice is essential.
Conclusion
Series and parallel resonance are fundamental concepts in AC circuit analysis. They help in understanding frequency response, impedance behavior, and energy transfer in electrical systems.
A clear understanding of resonance will make advanced topics like communication systems, signal processing, and power electronics much easier.
AKTU students should focus on both theoretical understanding and numerical problem-solving to master this topic.
Detailed Series & Parallel Resonance (Complete AKTU Guide)
Table of Contents
1. Introduction
2. Resonance Concept
3. Series Resonance
4. Derivation of Resonant Frequency
5. Resonance Graph
6. Parallel Resonance
7. Quality Factor
8. Bandwidth
9. Numerical Problems
10. Viva Questions
11. Conclusion
Introduction
Resonance is a very important concept in AC circuits. It occurs when inductive and capacitive effects cancel each other. This topic is very important for AKTU exams and is frequently asked in both theory and numericals.
Resonance Concept
Resonance occurs when:
XL = XC
Inductor stores energy in magnetic field and capacitor stores energy in electric field. At resonance, energy oscillates between them.
Series Resonance
In series RLC circuit:
Z = √(R² + (XL - XC)²)
At resonance:
XL = XC → Z = R (minimum)
Hence current becomes maximum:
I = V / R
Derivation of Resonant Frequency
Condition:
XL = XC
2πfL = 1 / (2πfC)
(2πf)² = 1 / LC
f = 1 / (2π√LC)
This is the resonant frequency formula used in exams.
Resonance Graph (Frequency vs Current)
At resonant frequency, current reaches maximum value.
Parallel Resonance
In parallel RLC circuit:
- Impedance is maximum - Line current is minimum
This is also called current resonance.
Although supply current is small, internal circulating currents are high.
Quality Factor (Q)
Q indicates sharpness of resonance.
Q = (1/R) √(L/C)
High Q → sharp peak Low Q → wide curve
Bandwidth
Bandwidth is defined as:
BW = f₂ - f₁
Also:
BW = f / Q
Lower bandwidth → better selectivity.
Numerical Problems
Problem 1:
L = 0.2 H, C = 50 µF Find resonant frequency.
f = 1 / (2π√LC)
= 1 / (2π√(0.2 × 50×10⁻⁶))
= 50.3 Hz (approx)
Problem 2:
R = 10Ω, L = 1H, C = 100µF Find Q factor.
Q = (1/R) √(L/C)
= (1/10) √(1 / 100×10⁻⁶)
= 10
Viva Questions
1. What is resonance?
2. Define resonant frequency.
3. What happens to impedance at resonance?
4. What is Q factor?
5. Difference between series and parallel resonance?
6. Why power factor becomes unity?
7. What is bandwidth?
Conclusion
Series and parallel resonance are essential for understanding AC circuit behavior. These concepts are widely used in communication, filters, and power systems.
For AKTU exams, focus on formulas, derivations, and numericals. Practice regularly to master this topic.
